Salesforce

Salesforce is a best-of-breed cloud customer relationship management app, enabling organizations to easily manage and track leads, contacts and opportunities. It is built on the Force.com platform, and can be readily extended with an expansive range of third-party marketplace apps and other Salesforce products that encompasses sales, marketing, customer service and commerce.

API version

The Salesforce connector uses Salesforce REST API.

Supported editions and versions

The Salesforce connector works with all Salesforce cloud instances, e.g. Professional, Enterprise, Unlimited, and Developer

It also works with Force.com apps.

How to connect to Salesforce on Workato

The Salesforce connector uses OAuth2 authentication to authenticate with Salesforce.

Configured Salesforce connection Configured Salesforce connection

  • Connection name

Give this Salesforce connection a unique name that identifies which Salesforce instance it is connected to.

  • Sandbox

To connect to a Salesforce Sandbox instance, simply use the login credentials for your sandbox account and select "yes" on this field.

  • Enable restricted IP

Relevant for organizations with IP whitelisting. Select yes to have all requests from Workato originate from a consistent, known IP address.

Fill in the above fields and click connect. A Salesforce connection pop-up prompts you to provide your Salesforce login credentials for OAuth2 authorization.

Salesforce authorization pop-up Salesforce authorization pop-up

  • Username

Username to connect to Salesforce.

  • Password

Password to connect to Salesforce.

Roles and permissions required to connect

Salesforce users can connect to Salesforce from Workato. We recommend that a separate user be created for integration purposes.

The connected user will have the same permissions through the Workato Salesforce connector as in Salesforce. They will be able to read and write the objects as specified in their Salesforce profile. The user profile should be setup to allow appropriate access to the requisite objects required for the recipes. The permissions can be edited via the connected user's profile in Salesforce.

API Enabled permission

The connected user's profile should be API enabled. API enabled permission - profile setup API enabled permission - profile setup

Standard and custom object permissions

To interact with an object in Salesforce, the connected user's profile needs to have permissions to read, write, edit, delete, view all, modify all for the standard object or custom object in your Salesforce organization.

Salesforce standard object permissions - profile setup Salesforce standard object profile permissions setup

Salesforce custom object permissions - profile setup Salesforce custom object profile permissions setup

Platform event permissions

In order to use platform events triggers and actions, you need platform events to be enabled in your Salesforce organization. You would need to set read and create permissions for the connected user's profile.

Salesforce platform events permissions - profile setup Salesforce platform events permissions - profile setup

Real-time trigger permissions

To use real-time triggers in Salesforce, workflow rules have to be set up in your Salesforce organization. These workflow rules require the Customize application permission under the Administrative Permissions tab to be setup, although the connected user does not need to be the user who sets these rules up.

Customize application permission - profile setup Customize application permission - profile setup

Working with the Salesforce connector

Can I connect more than one Salesforce account in a single recipe?

Yes, you may use up to 2. Simply use the Salesforce Secondary app on Workato, and you will be able to use both accounts in a single recipe. Find out more here.

Using real-time triggers

Workato offers real-time capabilities for 2 Salesforce triggers: New Object and New/Updated Object. This allows Workato to detect records created/updated in Salesforce immediately. Salesforce real-time triggers is enabled only for certain plans. Check the Pricing and Plans page or reach out to Workato sales representatives at +1 (844) 469-6752 to find out more.

These real-time triggers are powered by Salesforce workflow rules. Via these workflow rules, Salesforce monitors records for certain changes and notifies Workato immediately via an outbound message when these changes occur. These outbound messages will be received and processed by a Workato recipe as trigger events.

To set up these triggers, we need to:

  1. Create a Workato recipe with a Salesforce real-time trigger, and copy the generated endpoint URL from the trigger.
  2. Create a Salesforce workflow rule to monitor events we're interested in and send outbound messages to that endpoint URL when these events occur.
  3. Activate the workflow rule.
  4. Add trigger conditions in the recipe, if desired.
  5. Start the recipe.

In the following sections, we provide a detailed walkthrough to setup the real-time triggers:

Real-time trigger setup - new object

We go through the setup for the New object real-time trigger below. We will be setting up a real-time trigger for new contacts in Salesforce.

1) Select the trigger in Workato. You will be prompted to connect to your Salesforce account.

Select new object real-time trigger in Salesforce Select new object real-time trigger in Salesforce

2) Connect to Salesforce.

3) Select the specific object you wish to monitor in Salesforce. In this case, we'll select Contact.

Select specific object to monitor in Salesforce Select specific object to monitor in Salesforce

The trigger will provide you with an endpoint URL to setup a Salesforce workflow rule with. This URL will tell Salesforce to send real-time events about newly created contacts to this Workato recipe. Copy this URL to the clipboard for use in creating the Salesforce workflow rule.

Workato generates endpoint URL for Salesforce workflow rule Workato generates endpoint URL for Salesforce workflow rule

This endpoint URL is unique to the Salesforce organization connected to the trigger, the Salesforce object you've selected, and the Workato recipe. You will need to regenerate this endpoint URL again if you decide to change Salesforce connection, the Salesforce object monitored, or the Workato recipe.

4) Go to your Salesforce organization and click on Setup. Go to Create > Workflow & Approvals > Workflow rules and click on New rule to create a new workflow rule. This will bring you into the Salesforce workflow rule setup wizard.

In your Salesforce organization, go to Setup>Create>Workflow & Approvals>Workflow rules and click on New rule In your Salesforce organization, go to Setup>Create>Workflow & Approvals>Workflow rules and click on New rule

5) In step 1 of the setup wizard, select the same Salesforce object you have selected in the recipe.

Select specific object to monitor in Salesforce Select specific object to monitor in Salesforce

6) In step 2 of the setup wizard, set the workflow rule to be evaluated every time a record is created. We set the rule criteria to be Created Date not equal to null. Because no record will ever have a null date for the field Created Date, this ensures that the workflow rule will always be triggered when a record is created.

Setup the Salesforce workflow rule to be evaluated when record is created Setup the Salesforce workflow rule to be evaluated when record is created

7) In step 3 of the setup wizard, add a workflow action "New outbound message". This ensures that Salesforce will always notify our Workato recipe whenever a record is created, via sending an outbound message to that recipe's endpoint URL.

Add outbound message as the workflow action. Newly created contacts that meet the evaluation criteria will send an outbound message Add outbound message as the workflow action. Newly created contacts that meet the evaluation criteria will send an outbound message

8) Set up the outbound message using the endpoint URL we copied in Step 3, and save it.

Setup outbound message using endpoint URL generated by recipe Setup outbound message using endpoint URL generated by recipe

9) Save the workflow rule and activate it.

Activate workflow rule to start monitoring new contacts created in Salesforce Activate workflow rule to start monitoring new contacts created in Salesforce

10) Return to Workato and start the recipe. To test that the recipe is working, create a new contact in your Salesforce instance. Check that the recipe picks up the trigger event immediately to verify that the workflow rule is working.

If the trigger event is indeed picked up immediately, this means that your workflow rule and Workato trigger has been set up properly. While the recipe is running, it should monitor newly created records in Salesforce and process them as trigger events immediately. If your workflow requires additional logic to filter out certain records, add trigger conditions.

Real-time trigger setup - new and updated object

We go through the setup for the New and updated object real-time trigger below. We will be setting up a real-time trigger for new and updated leads in Salesforce.

1) Select the trigger in Workato. You will be prompted to connect to your Salesforce account.

Select new or updated object real-time trigger in Salesforce Select new and updated object real-time trigger in Salesforce

2) Connect to Salesforce.

3) Select the specific object you wish to monitor in Salesforce. In this case, we select Lead.

Select specific object to monitor in Salesforce Select specific object to monitor in Salesforce

The trigger will provide you with an endpoint URL to setup a Salesforce workflow rule with. This URL will tell Salesforce to send real-time events about newly created or updated contacts to this Workato recipe. Copy this URL to the clipboard for use in creating the Salesforce workflow rule.

Workato generates endpoint URL for Salesforce workflow rule Workato generates endpoint URL for Salesforce workflow rule

This endpoint URL is unique to the Salesforce organization connected to the trigger, the Salesforce object you've selected, and the Workato recipe. You will need to regenerate this endpoint URL again if you decide to change Salesforce connection, the Salesforce object monitored, or the Workato recipe.

4) Go to your Salesforce organization and click on Setup. Go to Create > Workflow & Approvals > Workflow rules and click on New rule to create a new workflow rule. This will bring you into the Salesforce workflow rule setup wizard.

In your Salesforce organization, go to Setup>Create>Workflow & Approvals>Workflow rules and click on New rule In your Salesforce organization, go to Setup>Create>Workflow & Approvals>Workflow rules and click on New rule

5) In step 1 of the setup wizard, select the same Salesforce object you have selected in the recipe.

Select specific object to monitor in Salesforce Select specific object to monitor in Salesforce

6) In step 2 of the setup wizard, set the workflow rule to be evaluated every time a record is created, and every time it's edited. We set the rule criteria to be Created Date not equal to null. Because no record will ever have a null date for the field Created Date, this ensures that the workflow rule will always be triggered when a record is created or updated.

Setup the Salesforce workflow rule to be evaluated when record is created or updated Setup the Salesforce workflow rule to be evaluated when record is created or updated

7) In step 3 of the setup wizard, add a workflow action "New outbound message". This ensures that Salesforce will always notify our Workato recipe whenever a record is created or updated, via sending an outbound message to that recipe's endpoint URL.

Add outbound message as the workflow action. Newly created or updated contacts that meet the evaluation criteria will send an outbound message Add outbound message as the workflow action. Newly created or updated contacts that meet the evaluation criteria will send an outbound message

8) Set up the outbound message using the endpoint URL we copied in Step 3, and save it.

Setup outbound message using endpoint URL generated by recipe Setup outbound message using endpoint URL generated by recipe

9) Save the workflow rule and activate it.

Activate workflow rule to start monitoring new leads created in Salesforce Activate workflow rule to start monitoring new leads created in Salesforce

10) Return to Workato and start the recipe. To test that the recipe is working, update a new object record. In this case, you should update an existing lead. Check that the recipe picks up the trigger event immediately to verify that the workflow rule is working.

If the trigger event is indeed picked up immediately, this means that your workflow rule and Workato trigger has been set up properly. While the recipe is running, it should monitor newly created or updated records in Salesforce and process them as trigger events immediately. If your workflow requires additional logic to filter out certain records, add trigger conditions.

Working with generic triggers in Salesforce

In Workato, a Trigger refers to a condition that is set to start off a recipe. All the triggers on the Salesforce connector deals with Objects. The name of the trigger tells you exactly what event must occur for a recipe to take place. The term "object" is exactly the same as how it is used within Salesforce itself, and refers to things such as leads, opportunities, accounts, as well as custom objects you may have created for your organisation. Simply click on the Object field's dropdown list and you will be able to see all the objects associated with the instance of Salesforce you have connected to a recipe. For example, you use the trigger "New Object" and select Lead as the object. Your recipe will trigger every time a new lead is created.

Working with generic create/update/search actions in Salesforce

When working with Salesforce Actions on Workato, you should find it extremely easy if you are familliar with the fields in the objects on your Salesforce account. When you select an object to use in a create/update/search action, you will see all the fields associated with that object appearing in your action. For example, if you were to choose Lead you will see fields like phone, email, lead status etc. Simply drag and drop pills into the associated fields you want to populate in a create/update action, or for the field you want to search with in the search action.

Working with attachments in Salesforce

Uploading

To upload an attachment to Salesforce using Workato, you can use the Create Object Action, and select Attachment under the Object field. Before that however, you need to have a step that downloads the file that is to be uploaded to Salesforce. You may use the Box action get file download URL, followed by using the utilities tool to upload it from the obtained URL, or a simillar flow of actions with another connector. You can check out this example here on how to download a file to Workato.

Downloading

To download an attachment from Salesforce, you can use the Download file Action. The file ID must be obtained from a previous step, usually from the Get object details step. Once that step is properly set up, you will be able to use the attachment as a pill in the other steps of the recipe, for example, you can use the Upload file action in the Box connector.

Working with SOQL in Salesforce

Salesforce Object Query Language (SOQL) is used to search your Salesforce data for specific information. SOQL syntax consists of a required SELECT statement which may be followed by a number of optional clauses (such as TYPEOF, WHERE, WITH, GROUP BY, etc.).

In a Workato recipe, the scheduled object query trigger will run SOQL queries with the following basic syntax: SELECT (list of fields) FROM (an object) WHERE (filter statements/sorting).

The recipe will automatically handle the SELECT FROM portion of your query. It will SELECT all fields FROM the object you choose from the pick list. For optional clauses, the trigger currently only supports WHERE conditions.

For a list of standard fields for major Salesforce objects, see: Salesforce Fields Reference.

Inputting SOQL WHERE Conditions (Syntax):

The WHERE clause follows field expression syntax. A fieldExpression is defined as follows: \ \ \.

Comparison operators: Comparison operators include the following: =, !=, <, <=, >, >=, LIKE, IN, NOT IN, INCLUDES, and EXCLUDES. Here is a simple example following fieldExpression syntax:

SOQL-1

For detailed information on how to use each comparison operator, see: Comparison Operators.

Logical operators: Multiple field expressions can be joined using logical operators. These include: AND, OR, and NOT. The basic syntax is as follows:

  • fieldExpressionX AND fieldExpressionY
  • fieldExpressionX OR fieldExpressionY
  • NOT fieldExpressionX.

Here is an example showing two fieldExpressions joined by a logical operator:

SOQL-2

For more information on logical operators, see: Logical Operators.

Date Formats and Date Literals:

To filter on date fields in a query, you must use Date only format. The syntax for this is: YYYY-MM-DD. To filter on dateTime fields in a query, you must use the format including: date, time, and time zone offset. There are three possible syntax formats for this:

  • YYYY-MM-DDThh:mm:ss+hh:mm
  • YYYY-MM-DDThh:mm:ss-hh:mm
  • YYYY-MM-DDThh:mm:ssZ.

In order to query a date or dateTime field, you may need to turn on formula mode if you are not using it already. This is needed to convert your timestamp to the ISO8601 format expected in SOQL. Also note that you do not need to use single quotes around date or dateTime values. For date fields, add ‘.to_date’ to the end of your date formula to convert your date or timestamp to the correct format.

SOQL-3

SOQL-4

For dateTime fields, the third syntax format is the simplest to use. After entering the formula to get your desired timestamp (eg: now, 2.weeks.ago.beginning_of_day, etc.), add ‘.strftime("%Y-%m-%dT%H:%M:%S%z")’ to the end of it.

SOQL-5

For more information on date formats and date literals, see: Date Formats and Date Literals

For additional help, see Salesforce documentation

Prevent schema errors with Fields list

When using a Salesforce trigger/action in a recipe, all object fields (standard and custom fields) are requested from Salesforce by default, even if these fields are not used in the recipe.

If a Salesforce admin changes the Salesforce object schema, e.g. deletes fields in the object, the recipe throws an error when making API requests to Salesforce for that object. This is because these deleted fields are still being requested from Salesforce by the recipe, which is an invalid request. On the other hand, if fields are added to the Salesforce object, there will not be any recipe errors as Workato will simply not request for these additional fields.

Such schema differences between Salesforce and Workato can be resolved by a schema refresh. However, if frequent schema changes are expected, we can utilize the Fields input field to control the fields that we request from Salesforce. This will ensure that schema changes unrelated to the recipe will not cause the recipe to break or experience errors.

Fields list

The Fields list input field allows users to select the fields they wish to use in the recipe. This ensures that the recipe will be affected only by changes to these subset of fields, and therefore minimize impact on the recipe due to schema changes.

The benefits of using the Fields list are:

  1. Improved recipe performance
  2. Improved recipe usability due to smaller datatree with only relevant datapills
  3. Minimizes impact on recipe by Salesforce object schema changes

How to use Fields list

Salesforce triggers and actions have an optional input field called Fields. This is a multiselect field for you to select the data fields you want to use in the recipe. If left blank, the Salesforce trigger/action will retrieve all data fields in the datatree by default.

Unconfigured fields selector Unconfigured fields selector. All account data fields are retrieved in the datatree by default.

All data fields of your selected object will be available in the Fields list.

Available base object fields Fields selector displays all available data fields for your selected object by default

By selecting any subset of these fields, the datatree will be regenerated to display only the selected datapills.

Configured base object fields selector Configuring the fields selector - the datatree is regenerated when any fields are selected

In Salesforce, you can choose to retrieve related objects' data as well, e.g. if your trigger is a new opportunity in Salesforce, we can retrieve data about the Salesforce account the opportunity is related to. If your trigger is a new case, we can retrieve data about the Salesforce contact, lead or account the opportunity is related to. To tell Workato the fields to select, first select the related objects you're interested in, then select the fields of this related obect you're interested in.

In the following example, we first selected account as the primary base object, then parent account as the join object. The Fields multiselect list is promptly populated with fields belonging to the parent account as well. Similarly, if the Fields list is not configured, all account and parent accountfields will be fetched from Salesforce.

Available join object fields Available join object fields will be shown when the related join objects is selected

All data fields of your selected base and related join objects will be available in the Fields list. By selecting any subset of these fields, the datatree will be regenerated to display only the selected datapills.

Configured join object fields selector Configuring the fields selector containing base and related join object data fields - the datatree is regenerated when any fields are selected

By limiting the datatree to only the fields we're interested in using, we mitigate the effects of Salesforce schema changes on our recipe.

Best practices

When starting to use Workato with your Salesforce account, we reccomend that you either do it on a sandbox account, or test on non-essential pieces of data. This would prevent any loss of crucial data, especially since actions performed through Workato cannot be undone.

Working with sandboxes on Workato

Salesforce sandboxes are isolated from your Salesforce production organization, so operations that you perform in your sandboxes don’t affect your Salesforce production organization, and conversely. Sandboxes are nearly identical to your Salesforce production organization. For a list of differences, see Sandbox Setup Tips and Considerations.

Troubleshooting

Here is a list of common errors that you may encounter, and links to how to rectify them.
